MAINTENANCE WORK ON CHASSIS AND ENGINE 92
9.39Installing the front wheel x
Warning
Danger of accidents Reduced braking due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
800080-11
– Clean and grease the shaft seal rings and bearing surface of the distance bush-
ings.
Long-life grease ( p. 172)
– Insert the distance bushings.
800079-11
– Lift the front wheel into the fork, position it, and insert the wheel spindle.
– Mount and tighten screw .
Guideline
Screw, front wheel spindle M24x1.5 40 Nm
(29.5 lbf ft)
– Operate the hand brake lever several times until the brake pads are lying correctly on
the brake disc.
– Remove the motorcycle from the work stand. ( p. 55)
– Pull the front wheel brake and push down hard on the fork several times to align the
fork legs.
