MAINTENANCE WORK ON CHASSIS AND ENGINE 128
100281-10
– Remove screws .
– Remove cover with membrane .
– Check the fluid level.
Fluid level under top level of container 4 mm (0.16 in)
» If the level of the coolant does not meet specifications:
– Correct the fluid level of the hydraulic clutch.
Hydraulic fluid (15) ( p. 169)
– Position the cover with the membrane. Mount and tighten the screws.
9.70Checking play in gas Bowden cable
400192-10
– Move the handlebar to the straight-ahead position. Move the throttle grip backwards
and forwards to ascertain the play in the gas Bowden cable.
Play in gas Bowden cable 3… 5 mm (0.12… 0.2 in)
» If the gas Bowden cable play does not meet specifications:
–
Adjust the play in the gas Bowden cable. x ( p. 129)
