PERIODIC SERVICE92
5. Accelerate the engine to remove the small portion of
air left in the fuel system.
6. If air still remains and the engine stops, repeat the
above steps.
BDraining Clutch Housing Water
The tractor is equipped with split pin plug under the clutch
housing.
After operating in rain, snow or tractor has been washed,
water may get into the clutch housing. Check it by pushing
in the split pin.
If water has entered into the clutch housing, remove the
plug and drain the water, then install the plug again.
BReplacing Fuse
The tractor electrical system is protected from potential
damage by fuses.
A blown fuse indicates that there is an overload or short
somewhere in the electrical system.
If any of the fuses should blow, replace with a new one of
the same capacity.
A Before replacing a blown fuse, determine why the fuse
blew and make any necessary repairs. Failure to
follow this procedure may result in serious damage to
the tractor electrical system. Refer to the
"TROUBLESHOOTING" section of this manual or your
local KUBOTA Dealer for specific information dealing
with electrical problems.
(1) Split pin plug
FUSE No. CAPACITY(A) Protected circuit
(1) 5 Engine ECU (Ignition key)
(2) 5 Main ECU (Ignition key)
(3) 5 Meter panel (Ignition key)
(4) 5 Combination switch
(5) 5 Work light
(6) 5 Starter relay
(7) 20 Engine ECU (Battery)
(8) 5 Main ECU (Battery)
(9) 5 Meter panel (Battery)
(10) 10 Hazard
(11) 10 Head Light
