TIRES, WHEELS AND BALLAST62
BRear Ballast
Add weight to rear wheels if needed to improve traction or
for stability. The amount of rear ballast should be matched
to job and the ballast should be removed when it is not
needed.
The weight should be added to the tractor in the form of
liquid ballast, rear wheel weights or a combination of both.
C Rear Wheel Weights (option)
The rear wheel weights can be attached to the rear wheel.
See your implement operator's manual for required
number of weights or consult your local KUBOTA Dealer
to use.
A Do not overload tires.
A Add no more weight than indicated in chart.
BLiquid Ballast in Rear Tires
Water and calcium chloride solution provides safe
economical ballast. Used properly, it will not damage tires,
tubes or rims. The addition of calcium chloride is
recommended to prevent the water from freezing. Use of
this method of weighting the wheels has the full approval
of the tire companies. See your tire dealer for this service.
Liquid weight per tire (75 Percent filled)
A Do not fill tires with water or solution more than 75% of
full capacity (to the valve stem level at 12 o'clock
position).
(1) Rear wheel weights
Maximum weight per wheel
47 kg x 3 Pieces
(310 lbs.)
Tire sizes 14.9-26 13.6-28 17.5L-24
Slush free at -10 (14 )
Solid at -30 (-22 )
[Approx. 1 kg (2 lbs.)
CaCl per 4 L (1 gal)
of water]
215 kg
(470 lbs.)
185 kg
(410 lbs.)
235 kg
(520 lbs.)
Slush free at -24 (-11 )
Solid at -47 (-52 )
[Approx. 1.5 kg (3.5 lbs.)
CaCl per 4 L (1 gal)
of water]
225 kg
(495 lbs.)
200 kg
(440 lbs.)
250 kg
(550 lbs.)
Slush free at -47 (-52 )
Solid at -52 (-62 )
[Approx. 2.25 kg (5 lbs.)
CaCl per 4 L (1 gal)
of water]
235 kg
(520 lbs.)
215 kg
(470 lbs.)
265 kg
(585 lbs.)
(1) Air
(2) Water
(A) Correct-75% Air compresses like a cushion
(B) Incorrect-100% Full Water can not be
compressed
0000012651.book Page 62 Thursday, October 1, 2015 3:53 PM
