61TIRES, WHEELS AND BALLAST
To avoid personal injury or death:
A Before jacking up the tractor, park it on a firm
and level ground and chock the front wheels.
A Fix the front axle to keep it from swinging.
A Select a jack that withstands the machine
weight and set it up as shown below.
BALLAST
To avoid personal injury or death:
A Additional ballast will be needed for
transporting heavy implements. When the
implement is raised, drive slowly over rough
ground, regardless of how much ballast is
used.
A Do not fill the front wheels with liquid to
maintain steering control.
BFront Ballast
Add weights if needed for stability (2WD, 4WD models)
and improve traction (4WD model). Heavy pulling and
heavy rear mounted implements tend to lift front wheels.
Add enough ballast to maintain steering control and
prevent tip over. Remove weight when no longer needed.
C Front End Weights (option)
The front end weights can be attached to the bumper. See
your implement operator's manual for required number of
weights or consult your local KUBOTA Dealer to use.
A Do not overload tires.
A Add no more weight than indicated in chart.
A The front end weights can be attached to the bumper
(option on 4WD models).
(1) Jack point
(1) Front end weights
(2) Bumper
Maximum weight
25 kg x 7 pieces
(386 lbs.)
