ELECTRICAL SYSTEM
L3560, L4060, L4760, L5060, L5460, L6060, WSM
9-S59
Hi-Lo Solenoid
1. Remove the cover.
2. Disconnect the connector (1).
3. Remove the Hi-Lo solenoid valve assembly.
4. Disassembling the Hi-Lo solenoid valve assembly.
5. Measure the resistance with an ohmmeter across the terminal
on the connector and valve body.
6. It is OK if the resistance comes to have shown in the table
below.
NOTE
• It is not necessary to adjust any kind of mode.
9Y1210824ELS0057US0
Resistance
Hi-Lo solenoid terminal to
valve body
10 to 12 Ω
(1) Connector (2) Hi-Lo Solenoid
KiSC issued 03, 2016 A

Kubota WSM L6060 Specifications

General

Engine Model	Kubota V2403-CR-TE4
Horsepower	62 HP
3-Point Hitch	Category I & II
Type	Compact Utility Tractor
Fuel Type	Diesel
Drive	4WD
Engine Type	4-cylinder, liquid-cooled diesel
Transmission	Hydrostatic (HST)
PTO Power	54 hp
Wheelbase	74.6 inches
Displacement	148.5 cu in (2.4 L)
Tire Size (Front)	12.4-16
