2MN/2N1-1
2-2-3
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Main PWB (MPWB) PARTS PWB MAIN ASSY SP
2 Engine PWB (EPWB) PARTS PWB ENGINE ASSY SP
3 Power source PWB (PSPWB) PARTS UNIT LOW VOLTAGE SP
4 High voltage PWB 1 (HVPWB1) PARTS UNIT HIGH VOLTAGE MAIN SP
5 High voltage PWB 2 (HVPWB2) PARTS UNIT HIGH VOLTAGE TRANSFER SP
6 Operation PWB (OPWB) PARTS PWB PANEL ASSY SP
7 Front PWB (FRPWB) PARTS PWB FRONT CLR ASSY SP
8 Feed PWB 1 (FPWB1) PARTS PWB FEED 1 ASSY SP
9 Feed PWB 2 (FPWB2) PARTS PWB FEED 2 ASSY SP
10 Relay PWB (RPWB) PARTS PWB JUNCTION ASSY SP
11 Motor control PWB (MCPWB) PARTS PWB MOTOR CONTROL ASSY SP
12 LSU relay PWB (LSURPWB) PARTS PWB LSU JUNC CLR ASSY SP
13 APC PWB K (APCPWB-K) -
14 APC PWB M (APCPWB-M) -
15 APC PWB C (APCPWB-C) -
16 APC PWB Y (APCPWB-Y) -
17 PD PWB K (PDPWB-K) -
18 PD PWB M (PDPWB-M) -
19 PD PWB C (PDPWB-C) -
20 PD PWB Y (PDPWB-Y) -
21 Drum PWB K (DRPWB-K) -
22 Drum PWB M (DRPWB-M) -
23 Drum PWB C (DRPWB-C) -
24 Drum PWB Y (DRPWB-Y) -
25 Transfer PWB (TRPWB) -
26 Fuser PWB (FUPWB) -
27 Fuser IH PWB (FIHPWB) -
28 RFID PWB (RFPWB) PARTS PWB RFID ASSY SP
29 Interface PWB (IFPWB) PARTS PWB KUIO ASSY SP
30 Current PWB (CRPWB) PARTS PWB CURRENT AVE ASSY SP
To Next Page
