2-7
Installing and Setting up the Machine > Connecting the Machine and Other Devices
Connecting the Machine and Other Devices
Prepare the cables necessary to suit the environment and purpose of the machine use.
When Connecting the Machine to the PC via USB
When Connecting the Machine to the PC or Tablet by network cable, Wi-Fi, or Wi-Fi direct
Cables that Can Be Used
If you are using wireless LAN, refer to the following.
Configuring the Wireless Network (page 2-26)
Connection Environment Function Necessary Cable
Connect a LAN cable to the
machine.
Printer/Scanner/Network FAX LAN cable (10BASE-T, 100BASE-TX,
1000BASE-T)
Connect a USB cable to the
machine.
Printer/Scanner (TWAIN/WIA) USB 2.0 compatible cable (Hi-Speed USB
compliant, max. 5.0 m , shielded)
Using a cable other than a USB 2.0 compatible cable may cause failure.
Ta b let
Network cable
connection
Network
Wi-Fi access point
Wi-Fi
connection
*1
Wi-Fi Direct
connection
*1
*1 Only for models with Wi-Fi.
To Next Page
