Kyocera FS-9120DN User Manual

Appendix B Host Computer Interface
B-2
[ ]: Signal names in the Auto mode and Nibble (high) mode (IEEE1284).
In the Auto mode and Nibble (high) mode, these signals are bi-
directional.
Detailed descriptions of the signals follow.
Strobe* [nStrobe] (Pin 1)
A negative-going Strobe* pulse causes the printer to read and
latch the data on the Data 0 [1] to Data 7 [8] signal lines.
Data 0 [1] to Data 7 [8] (Pins 2 to 9)
These eight signals form the data byte sent from the host
computer to the printer. Data 7 [8] is the most significant bit.
Acknowledge* [nAck] (Pin 10)
This negative-going pulse acknowledges the previous charac-
ter received by the printer.
Busy [Busy] (Pin 11)
This signal is high when the printer is busy and low when it
is able to accept more data.
Paper Empty [PError] (Pin 12)
This signal goes high when the printer has received a print
job and run out of paper.
Online [Select] (Pin 13)
This signal is high when the printer is online and low when
the printer is offline. It goes low when the GO key is pressed
to set the printer offline.
+5 V DC (Pin 18)
This line is connected to the printer’s +5 V DC line (+5 V ±0.5
V, maximum 400 mA [Serial and Parallel total], fused).
Error* [nFault] (Pin 32)
When the high-speed parallel line control is on (FRPO O2=2),
this line returns error status.
Power Ready (Pin 35)
This signal is high when the printer is turned on.
The Paper Empty, Online, and Error signals are not used un-
less enabled by the FRPO command (O2 parameter).
This printer supports the Hi-Speed USB 2.0. USB (Universal
Serial Bus) interface specifications and interface signals are
as follows.
Basic specification
Complies with the Hi-Speed USB 2.0.
Connectors
Printer: B-type receptacle (female) with upstream port
Cable: B-type plug (male)
Cable
Use a shielded cable that complies with USB 2.0 and not long-
er than 5 meters (16 feet).
Transfer Mode
Full speed (max. 480 Mbps)
Power Control
Self-power device
USB Connector Pin Assignment
NOTE
2. USB Interface
2.1 Specifications
2.2 Interface Signals
Pin Signal Description
1 Vbus Power supply (+5 V)
2 D- Data transmission
3 D+ Data transmission
4 GND Signal ground
Shell Shield
Table B-2

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
