Kyocera FS-9120DN User Manual

6-1
Chapter 6 Fonts
This appendix explains the types of fonts you can use with the printer. A font is a set of characters of a particular design. The
design is referred to as a typeface. Several characteristics identify a font. These include the code set (For details on the code sets,
read the
PRESCRIBE Commands Technical Reference on the supplied Kyocera Mita Document Library CD-ROM), spacing, pitch,
height, style, stroke weight, and typeface family.
List of Fonts
This section contains a full list of the printer’s internal fonts. The printer has 80 PCL fonts and 136 PostScript Level 3 compatible
fonts. You can print the font list from the printer by using the printer’s operator panel key. To print a list of fonts, refer to
Printing
a List of Fonts on page 3-27
. Font may be downloaded to the printer’s memory from a option memory card or hard disk.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
