Chapter 2 Handling Paper
2-6
The following explains the produre for loading paper can be loaded into the two paper cassettes and the MP tray.
Fan the paper, then tap it on a level surface.
This avoid media jams or skewed printing.
Figure 2-4
Up to about 500 sheets of standard paper (80 g/m
2
) can be
loaded into the each paper cassette.
Inch specifications
Each paper cassette can be set to hold paper of any desired
size from 11 × 17 to 5-1/2 × 8-1/2".
Metric specifications
Each paper cassette can be set to hold paper of any desired
size from A3 to A5R.
Pull the paper cassette out toward you as far as it
will go. Do not pull more than one paper cassette out
at a time.
Figure 2-5
Hold the paper guide and move it to align the paper
guide with the required paper width. Paper sizes are
marked inside the paper cassette.
Figure 2-6
Figure 2-7
Hold the paper stopper and move it to align with the
required paper length.
Figure 2-8
Set the paper flush against the left-hand wall of the
paper cassette.
Figure 2-9
4. How to Load Paper
IMPORTANT
4.1 Loading Paper into the Paper Cassette
1
2
3
4
To Next Page
