Kyocera FS-9120DN User Manual

Chapter 3 Using the Operator Panel
3-19
2.2.4 Changing the Interface Parameters
The printer is equipped with both a parallel and serial inter-
face or a network interface. Various printing environment
parameters such as the default emulation can be changed in-
dependently on different interfaces by using the printer’s
menu selection system. Select the interface to apply the
changes in the procedure described below.
This interface selection described below does not select
which interface data will be received from. The printer auto-
matically selects an interface.
Changing Parallel Interface Modes
The parallel interface supports a bi–directional/high–speed
mode according to IEEE standards. Normally, this interface
is used under the default setting Auto. For details, see
Appendix B Host Computer Interface . After setting the inter-
face, be sure to reset the printer or turn the power off at least
once. The new setting will be enabled thereafter.
Press the MENU key.
Press the  or  key repeatedly until Interface >
appears. One of the interface names shown below
appears, indicating the current interface.
Parallel (default)
USB
Network
Option (only when an optional network interface
card is installed)
Serial
(only when an optional serial interface board
is installed)
Press the ENTER key. A blinking question mark (?)
appears.
If Parallel is not displayed, press the  or  key
repeatedly until Parallel appears.
Press the ENTER key again.
Press the  key. The message display changes to the
communication mode menu.
Press the ENTER key. A blinking question mark (?)
appears.
Press the  or  key to display the desired mode.
The display changes as shown below. Press the
ENTER key.
AUTO (default)
Normal
High speed
Nibble (high)
Press the MENU key. The message display returns to
Ready.
Changing Serial Interface Modes
You can set the baud rate, data bits, stop bits, parity, and pro-
tocol for the serial interface.
This section applies to the printer having the optional serial
interface board kit (IB-11) installed.
Press the MENU key.
Press the  or  key repeatedly until Interface >
appears. One of the interface names shown below
appears, indicating the current interface.
Parallel (default)
USB
Network
Option (only when an optional network interface
card is installed)
Serial
(only when an optional serial interface board
is installed)
Press the ENTER key. A blinking question mark (?)
appears.
Press the  or  key repeatedly until Serial ap-
pears.
Press the ENTER key again.
NOTE
Interface >
?Parallel
>Parallel I/F
?Nibble (high)
1
2
3
4
5
6
NOTE
Interface
?Parallel
Interface
?Serial
7
8
1
2
3
4
5

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
