Replacing the bezel
Use this information to replace the bezel.
About this task
To install the bezel, complete the following steps:
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 33.
2. Turn off the server and peripheral devices and disconnect the power cords
and all external cables, if necessary.
3. Remove the cover (see “Removing the cover” on page 36).
4. Insert the tabs on the bottom of the bezel into the holes on the chassis.
5. Rotate the bezel upward to the server and reinstall the screws.
Note: Use the T8 Torx screwdriver that comes with the new bezel to install
the bezel.
Figure 194. Bezel removal
Figure 195. Bezel installation
Chapter 6. Removing and replacing components 289
