Lenze 9325 User Manual

Function block library
7-104

SHB9300CRV EN 2.0
Function
l Quick stop (QSP)
l Operation inhibited (DISABLE)
l Controller inhibit (CINH)
l TRIP SET
l TRIP RESET
l Parameter-set changeover (PAR)
l Controller status
7.6.30.1 Quick stop (QSP)
The controller is braked to standstill following the deceleration ramp C0105. It generates a holding
torque.
l Thisfunctioncanbecontrolledvia3inputs.
– Control word CAN-CTRL bit 3 from CAN-IN1
– Control word AIF-CTRL bit 3 from AIF-IN
– Control word C0135 bit 3
l All inputs are OR linked.
l C0136/1 indicates the control word C0135
7.6.30.2 Operation inhibited (DISABLE)
When being in this status, the drive cannot be started with the command: controller enable. The
power end stages are inhibited. All controllers are reset.
l Thisfunctioncanbecontrolledvia3inputs.
– Control word CAN-CTRL bit 8 from CAN-IN1
– Control word AIF-CTRL bit 8 from AIF-IN
– Control word C0135 bit 8
l All inputs are OR linked.
l C0136/1 indicates the control word C0135
7.6.30.3 Controller inhibit (CINH)
The power end stages are inhibited. All controllers are reset.
l Thisfunctioncanbecontrolledvia6inputs.
– Terminal X5/28 (LOW = controller inhibit)
– Control word CAN-CTRL bit 9 from CAN-IN1
– Control word AIF-CTRL bit 9 from AIF-IN
– Control word C0135 bit 9
– Free inputs DCTRL-CINH1 and DCTRL-CINH2
l All inputs are OR linked.
l C0136/1 indicates the control word C0135
