Technical data
3-2

SHB9300CRV EN 2.0
3.2 General data/application conditions
Field Values
Vibration resistance Germanischer Lloyd, general conditions
Permissible moisture Humidity class F without condensation
(average relative humidity 85 %)
Permissible temperature ranges during transport of the controller: -25
îš•
C
¡
+70
îš•
C
during storage of the controller: -25
îš•
C
¡
+55
îš•
C
during operation of the controller: 0
îš•
C
¡
+40
îš•
C without power derating
+40
îš•
C
¡
+55
îš•
C with power derating (units 9321-9326)
+40
îš•
C
¡
+50
îš•
C with power derating (units 9327-9332)
Permissible installation height h h

1000 m amsl without power derating
1000 m amsl
h

4000 m amsl with power derating
Permissible pollution VDE 0110 part 2 pollution degree 2
Noise emission Requirements to EN 50081-2, EN 50082-1, IEC 22G-WG4 (Cv)21
Limit value class A to EN 55011 (industrial premises) with mains filter A
Limit value class B to EN 55022 (residential area) with mains filter B and installation in control cabinet
Noise immunity Limit values maintained using mains filter.
Requirements to EN 50082-2, IEC 22G-WG4 (Cv) 21 .
Requirements Standard Severitye
Running time EN61000-4-2 3, i.e. 8 kV with air discharge and 6 kV with contact discharge
RF interference
(enclosure) EN61000-4-3 3, i.e. 10 V/m; 27 to 1000 MHz
Burst EN61000-4-4 3/4, i.e. 2 kV/5 kHz
Surge
(on mains cable) IEC 1000-4-5 3, i.e. 1,2/50
³
s, 1 kV phase-phase, 2 kV phase-PE
Insulation strength Overvoltage category III to VDE 0110
Packaging to DIN 4180
9321 to 9332: Delivery packaging
Type of protection IP20
IP41 on the heat-sink side for thermal separation (punching)
NEMA 1: Protection against contact
Approvals CE: Low-Voltage Directive
UL508: Industrial Control Equipment
UL508C: Power Conversion Equipment
