Configuration
7-244

SHB9300CRV EN 2.0
FAIL-QSP
Deceleratesthedriveto standstillwithinadefinedtime.Setpoint selectionsfor delaysinprogramsets
are not considered.
l Brakes the drive to standstill along the QSO ramp.
l The time for the QSP ramp is set via the dialog box ”Basic settings”.
l Factory setting of FAIL-QSP: (
&
8-6)
7.7.2 Setting of reactions
1. Click ”Parameter menu” in the ”Basic settings” dialog box.
2. Select the menu ”Dialog Diagnostics” by a double click.
Fig. 7-191 Dialog box ”Diagnostics 9300”
