Commissioning
5-13
 SHB9300CRV EN 2.0
Code Description
C0005=10000 The configuration C0005=10000 allows an electronical solution for a mechanical cam. Additional features and
functions such as stretching / compression / phase trimming in X- and Y-direction are made available.
l Master value
C0425 Encoder constant of the master value
l Cam profile data
C1300-C1317 The cam profile data are determing with the generation of the profile. Usually, they do not have to be changed
separately.
C1420 Determines the profile to be used when a event input is activated (digital input E1 = LOW).
l Contouring error evaluation
C1380/1 and C1380/2 Determine comparison window and hysteresis of the contouring error evaluation.
l Adjustment values
C0472/2 Influence of speed precontrol
C0472/3 Influence of torque precontrol
C1477/2 Contouring error limit (in s_units)
C0472/4 Reduction factor for contouring error warning
Warning limit C0472/4 x C1477/2
l Profile influence
C0472/1 Stretching / compression X axis (100% = no stretching / compression)
C1476/1 Phase trimming in X-direction
C1477/1 Phase trimming in Y-direction
C1476/16 TOUCH-PROBE position in X-direction
C472/9 Stretching/compression of Y-axis
C472/10 Torque limit value
5.9 Basic configuration
5.9.1 Predefined basic configurations
Several predefined signal configuration can be loaded by using C005. The numbers are used
according to the following:
C0005 = 1 X X X X
Control
0 Terminal control
1 Control via LECOM A/B/LI
3 Control via AIF (INTERBUS,PROFIBUS)
5 Control via system bus (CAN)
Terminal supply
0 - External supply of control terminals
1 - Internal supply of control terminals
Additional functions (see chapter 5.9.5 ff.)
0 - None
1 - Homing function
2 - Clutch function
3 - Switch points
8 - Mark-controlled correction of the master value
9 - Mark-controlled correction of the act. value
Control mode
0 - Instead of a mechanical cam*(see chapeter 15.1)
1 - Welding bar drive*(see chapter 15.2)
2 - Operation with position storage*(see chapter LEERER MERKER)
*- Incremental master value
Identification
1-Cam
