3 Product informaon
3.1 Idencaon of the products
Each device is provided with a nameplate containing the device data. Detailed informaon
about the nameplate data can be found in the product catalog.
3.2 Features
The following gure provides an overview of the elements and connecons on the device.
Posion, size and appearance of elements and connecons may vary depending on the
opons selected for the device.
Controller c520
X61
X62
X237
X16
X50
X2x6, X2x7
X53
Cable fixing
PROFINET Device
Option
Reset
Without function
PE connection
Cable fixing
24 V supply
Commissioning, diagnostics
Ethernet
EtherCAT master
USB2
USB1
SD card
Status LEDs
3.3 SD card
An already inserted SD card is included in the scope of supply of the controller.
The combinaon of control technology soware and applicaon data on the SD card ensures
that the data match the prevailing applicaon in the present version. The SD card serves to
easily exchange data in a dierent device.
The SD card is used as memory for the following applicaon data:
•
PLC boot project with parameter descripon
•
Applicaon credit for the FAST applicaon soware
•
Retain and logbook data
•
User data (SD card/userData folder)
•
Open source license descripon
Note:
•
The controller only works with a plugged-in SD card!
•
Removal of the SD card while the controller is running will lead to a system failure!
•
The SD card is required for the system start since it contains the system les for the
starng process.
•
If the SD card is removed, the controller must be restarted to enable a new access to the
card!
The operang system of the controller and the applicaon soware »FAST« are stored in the
internal ash memory of the controller.
For using a rmware update, include a memory reserve of 200 MB on the SD
card!
Product informaon
Idencaon of the products
12
