Assignment of the user data depending on the data type
Depending on the data type used, the user data is assigned as follows:
Data type Length User data assignment
Byte 1 Byte 2 Byte 3 Byte 4 Byte ...
String x bytes Data (x bytes)
U8 1 byte Data 0x00
U16 2 bytes High byte Low byte
Data Data
U32 4 bytes High word Low word
High byte Low byte High byte Low byte
Data Data Data Data
8.2.5 Monitoring
The parameters for seng network monitoring funcons are described below.
Parameter
Address Name / seng range / [default seng] Informaon
0x2859:001 PROFINET monitoring: Watchdog elapsed Selecon of the response to a permanent interrupon of the
communicaon to the IO controller.
Corresponding error code: 33168 | 0x8190 "PROFINET: Watchdog me-
out"
0 No response
1 Fault > CiA402
2 Warning
0x2859:002 PROFINET monitoring: Data exchange exited Selecon of the response to exing the "Data Exchange" state.
Corresponding error code: 33171 | 0x8191 "PROFINET: Exit Data
Exchange"
0 No response
1 Fault > CiA402
2 Warning
0x2859:003 PROFINET monitoring: Invalid conguraon Selecon of the response triggered by the recepon of invalid
conguraon data.
Corresponding error code: 33414 | 0x8286 "PROFINET: Conguraon
error"
0 No response
1 Fault > CiA402
2 Warning
0x2859:004 PROFINET monitoring: Inialisaon error Selecon of the response triggered by the occurrence of an error during
the inialisaon of the network component.
Corresponding error code: 33170 | 0x8192 "PROFINET: Inialisaon
error"
0 No response
1 Fault > CiA402
2 Warning
0x2859:005 PROFINET monitoring: Invalid process data Selecon of the response triggered by the recepon of invalid process
data.
Process data marked as invalid (IOPS is "BAD") are received by the IO
Controller. Typically in case of
•
a PLC in STOP state,
•
alarms,
•
acyclic demand data.
Corresponding error code: 33171 | 0x8193 "PROFINET: Invalid cyclic
process data"
0 No response
1 Fault > CiA402
2 Warning
Conguring the network
PROFINET
Monitoring
77
