Driving modes and rigging for on-road driving
6.6 Rigging the auxiliary hoist
Operating Instructions GMK5250L 3 302 633 en 6 - 65
27.09.2017
Disconnecting a
connection
Lowering the lifting frame
• Press the buttons (3) and (4).
• Press the buttons (2) until the locking
points (1) are relieved.
Retracting the locking cylinders
• Open the safety valve (3) – lever parallel with
the line.
• Press the button (2) until the locking cylin-
ders (1) are fully extended.
Lowering the auxiliary hoist
• Press the button (2) until the auxiliary
hoist (1) is completely lowered.
