10.4 Operation of the rated capacity limiter
Operating Instructions GMK5250L 3 302 633 en 10 - 29
27.09.2017
10.4 Operation of the rated capacity limiter
The rated capacity limiter is abbreviated to RCL (Rated-Capacity-Limiter) in
these operating instructions.
If the truck crane's current rigging mode is registered properly, the RCL will
prevent the permissible lifting capacity from being exceeded and the truck
crane from being overloaded.
The current rigging mode is registered via
– Measurements,
– acquired via manual entry.
During operation of the crane, a visual and acoustic early warning is issued
before the load limit is reached and then the functions are shut down that
would lead into the overload range.
G
Risk of accidents due to an incorrectly set RCL!
Ensure that the current rigging mode is correctly entered Before starting
crane operation. Incorrect entries will give you a false sense of security.
This may result in the truck crane overloading and causing an accident!
acquired via measurements Acquired via manual entry
– Main boom length
– Main boom angle
– Current load
– Lattice extension angle
1)
– Outrigger span
– Counterweight
– Length of lattice extension
– Angle of the lattice extension
2)
– Reeving
1)
Lattice extension – luffable
2)
Lattice extension – can be angled
G
Risk of accidents due to overridden or faulty RCL!
The RCL must never be overridden.
It is prohibited to work if the RCL is switched off, overridden, out of service
or faulty!
G
Danger of overturning in two-hook operation!
The rated capacity limiter only ensures safety for single hook operation!
Two-hook operation is not permitted.
