Cleaning and care
100
Removing the door
The door weighs approx. 10kg.
The oven door is connected to the
hinges by retainers.
Before removing the door from the
retainers, the locking clamps on both
hinges have to be released.
 Open the door fully.
 Release the locking clamps by
turning them as far as they will go.
The oven can be damaged if you
remove the door incorrectly.
Do not pull the door horizontally off
its retainers, as they will spring back
against the oven.
Do not pull the door off the retainers
by the handle, as the handle could
break off.
 Raise the door up till it rests partially
open.
 Hold the door on either side and pull
it diagonally upwards from the hinge
guides. Make sure that the door is
straight.

Miele H 7860 BP Specifications

General

Current	10 A
Connected load	3700 W
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	1.1 kWh
Energy consumption (forced convection)	0.71 kWh
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Convection cooking	Yes
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Control type	Touch
Door material	Glass
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Timer type	Digital
Timer modes	Cooking time, End cooking time

Weight and Dimensions

Depth	569 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	595 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	593 mm
