Miele H 7860 BP User Manual

Cleaning and care
93
Removing normal soiling
The fibreglass seal around the front
of the oven should be handled
carefully. Do not rub and scour it.
Ideally, you should avoid cleaning it.
Removing normal soiling
 It is best to remove normal soiling
immediately using a clean sponge
and a solution of hot water and
washing-up liquid, or a clean, damp
microfibre cloth.
 Remove any residual cleaning agent
thoroughly with clean water.
This is particularly important for any
parts with a PerfectClean finish, as
cleaning agent residues will impair
the non-stick properties.
 After cleaning, wipe the surfaces dry
using a soft cloth.
Cleaning the food probe
 Clean the food probe by hand or in
the dishwasher.
Removing stubborn soiling
(excluding the FlexiClip
telescopic runners)
Spilled fruit and roasting juices may
cause lasting discolouration or matt
patches on surfaces. This
discolouration will not affect the
functional characteristics of the
surface finish.
Do not attempt to remove these
marks. Clean them following the
instructions given here.
 Baked-on deposits can be removed
with a glass scraper or with a
stainless steel spiral pad, hot water
and washing-up liquid.
To clean the glass covering of the
camera, do not use stainless steel
spiral pads. Only use the scouring pad
of a washing-up sponge for this
purpose.
Using oven cleaners
 Very stubborn soiling on PerfectClean
surfaces can be cleaned using Miele
Oven Cleaner. This cleaner must only
be applied to cold surfaces.
If the oven spray gets into gaps and
openings, a strong odour is
generated during subsequent
cooking programmes.
Do not spray the oven cleaner onto
the roof of the oven compartment.
Do not spray the oven cleaner into
the gaps and openings of the oven
compartment walls and rear wall.
 Follow the instructions on the
packaging.
Oven cleaners from other
manufacturers must only be used in a
cold oven and must not be left on for
longer than 10minutes.
 If necessary, the scouring pad on the
back of a non-scratching washing-up
sponge can be used to remove the
soiling after the soaking time.
 Remove any residual cleaning agent
thoroughly with clean water.
 Dry all surfaces with a soft cloth.

Miele H 7860 BP Specifications

General

Current	10 A
Connected load	3700 W
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	1.1 kWh
Energy consumption (forced convection)	0.71 kWh
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Convection cooking	Yes
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Control type	Touch
Door material	Glass
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Timer type	Digital
Timer modes	Cooking time, End cooking time

Weight and Dimensions

Depth	569 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	595 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	593 mm
