Miele H 7860 BP User Manual

Controls
21
Symbols
The following symbols may appear in the display:
Symbol Meaning
 This symbol indicates that there is additional information and
advice about using the appliance. Select OK to confirm the
information.
…  This indicates that there are more options available, which are
not visible because there is not enough space in the display.
 Alarm
 Minute minder
       Some settings, e.g. display brightness and signal tone volume,
are selected using a segment bar.
 The system lock or sensor lock is on (see “Settings – Safety”).
The controls are locked.
 Core temperature when using the food probe
 Remote control (only appears if you are in the Miele@home
system and have selected the Remote control| On setting).
 SuperVision (only appears if you are in the Miele@home system
and have selected the SuperVision| SuperVision display| On setting)

Miele H 7860 BP Specifications

General

Current	10 A
Connected load	3700 W
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	1.1 kWh
Energy consumption (forced convection)	0.71 kWh
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Convection cooking	Yes
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Control type	Touch
Door material	Glass
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Timer type	Digital
Timer modes	Cooking time, End cooking time

Weight and Dimensions

Depth	569 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	595 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	593 mm
