Miele H 7860 BP User Manual

Installation
*INSTALLATION*
117
Electrical connection
 Danger of injury!
Miele cannot be held liable for
unauthorised installation,
maintenance and repair work as this
can be dangerous to users.
Connection to the electrical mains
may only be carried out by a
qualified electrician in accordance
with national and local regulations
and the additional regulations of the
local electrical supply companies.
Connection of this appliance must
comply with national and local safety
regulations.
Connection to a switched socket is
recommended as this provides easier
access in the case of a service call.
If the appliance is hardwired or if the
switch is not accessible after
installation, an additional means of
disconnection must be provided for all
poles.
Suitable means of disconnection
include switches with an all-pole
contact gap of at least 3mm. These
include isolator switches, fuses and
relays in accordance with the wiring
rules AS/NZS3000.
Voltage, rated load and fuse rating
are given on the data plate situated at
the front of the oven compartment.
Please ensure the connection data
matches the household supply.
When contacting Miele, please quote
the following:
- Model number
- Serial number
- Connection data (voltage/frequency/
maximum rated load)
If the mains connection cable is
damaged, it must be replaced by a
suitably qualified electrician with a
specialist connection cable of type
H05VV-F, available from Miele, in
order to avoid a hazard.
Temporary or permanent operation with
a self-sufficient or non-mains
synchronous energy supply system
(e.g. isolated networks, back-up
systems) is possible. A requirement for
the operation is that the energy supply
system complies with all current local
and national requirements that apply to
stand-alone, solar and/or battery
systems.
The protective measures provided in
the domestic installation and in this
Miele product must also be assured in
their function and operation in isolated
operation or in non-mains synchronous
operation, or replaced with equivalent
measures in the installation.
Oven
Ovens are supplied with a 3-core cable
for connection to a 230V, 50Hz
alternating current supply.
Fuse rating is 16A.
Maximum rated load: see data plate.

Miele H 7860 BP Specifications

General

Current	10 A
Connected load	3700 W
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	1.1 kWh
Energy consumption (forced convection)	0.71 kWh
Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Number of ovens	1
Total oven power	- W
Convection cooking	Yes
Full surface grill	-
Oven thermostat range	30 - 300 °C
Number of shelf positions	5
Total oven(s) interior capacity	76 L
Door hinge	down
Control type	Touch
Door material	Glass
Product color	Stainless steel
Control position	Top front
Appliance placement	Built-in
Timer type	Digital
Timer modes	Cooking time, End cooking time

Weight and Dimensions

Depth	569 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width	568 mm
Installation compartment height	595 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	593 mm
