Status Screen System Interface
4 - 46 Operator’s Manual of Anesthesia System
Figure 4-44 Gas Supply Pressure Monitoring
To change the gas supply pressure unit, perform the following settings:
1. Select the soft key > [System] soft key (system password required) > [Setup] >
[Language/Unit] tab.
2. Set [Gas Supply Pressure] to [kPa], [psi] or [bar].
4.8.3 AGSS
The AGSS status is displayed when the system is configured with AGSS. The float is used to indicate the
AGSS flow rate. Rotate the knob clockwise or anticlockwise the AGSS flow control knob until the float in
the Status Screen is located between Min and Max scale lines. When the system enters the standby
status, the AGSS is off and the float is in the [Off] status.
NOTE: Read the AGSS flow rate based on the position of the upper surface of
the float.
Figure 4-45 AGSS
Gas Supply Pressure
AGSS
Float
