Safety Designations Product Specifications
10 - 4 Operator’s Manual of Anesthesia System
• The pressure restriction device, expiratory volume monitor and breathing system with alarm system also
comply with ISO 80601-2-13.
• AG monitor in compliance with ISO 80601-2-55.
10.2 Safety Designations
10.3 Physical Specifications
Type of Protection against Electric
Shock:
Class I equipment with internal electric power supply.
Where the integrity of the external protective earth
(ground) in the installation or its conductors is in doubt, the
equipment shall be operated from its internal electric power
supply (i.e., battery supply).
Degree of Protection against Electric
Shock:
Type BF, defibrillation-proof
Rated voltage and frequency of
equipment:
External electric power supply:
AC: 100V to 120 V, 50/60 Hz
Internal Battery:
12V 32Ah (two pieces)
12V 16Ah (one piece)
Input power of equipment: 100V to 120V, 10A
Mode of Operation: Continuous
Degree of Protection against Hazards of
Explosion:
Not for use with flammable anesthetics.
Degree of Protection against Harmful
Ingress of Water:
IPX1
Electrical Connection between
Equipment and Patient:
Electrical connections
Degree of Mobility: Mobile (including the base and casters)
Disinfection methods: Steam autoclavable or disinfectable
Application parts with protection
against electric shock:
All application parts
Signal input or output part: Both signal input and output parts
Permanent or non-permanent
installation:
Non-permanent installation
TABLE 10-2 Safety Designations
Dimensions: Height: 1490 mm (59 in)
Width: 910 mm (36 in)
Depth: 705 mm (28 in)
Weight: ≤160 kg (353 lbs)(Standard configured mass)
≤290 kg (639 lbs)(Maximum configured mass)
Worktable (stainless steel): Weight limit: 30kg (66 lbs)
Width: 590 mm (23 in)
Depth: 325 mm (13 in)
Height: 850 mm (33 in)
External Auxiliary Worktable: Weight limit: 15 kg (33 lbs)
Width: 480 mm (19 in)
Depth: 310 mm (12 in)
TABLE 10-3 Physical Specifications
