Connect Anesthesia System to Patient Monitor Installation and Disassembly
3 - 12 Operator’s Manual of Anesthesia System
3.9 Connect Anesthesia System to Patient
Monitor
3.9.1 Connect Anesthesia System to Patient Monitor Through Serial
Interface
The anesthesia system can be connected to a Mindray patient monitor through a serial interface and
the BeneLink module to send the ventilation modes, parameters, alarms, alarm limits, waveforms and
patient information to the patient monitor via the MR-WATO protocol.
The anesthesia system can be connected to the Philips patient monitor through a serial interface and
the IntelliBridge module to send the partial ventilation modes, parameters, alarms, alarm limits and
waveforms of the anesthesia system to the Philips patient monitor via the Philips IntelliBridge
protocol.
1. The communication cable is connected to the communication interface of the anesthesia
system on one end and connected to the matched interface of the monitor on the other end.
2. Select the icon to open the [Setup] menu.
3. Select the [System] soft key, enter the system password and confirm the password.
4. Select the [Network] tab in the system menu.
5. Select the [Serial] tab.
6. Set [Protocol] to [MR-WATO] or [Philips].
7. Configure related settings. See 4.7.8.4 (Pages 4-41) "Network".
3.10 Connect Anesthesia System with eGateway
The anesthesia system can be connected to the ADT server through eGateway to download
patient information from the ADT server. See 4.2.1.2 (Pages 4-5) "Retrieve Patient Information from
ADT Server".
With the anesthesia system connected to the eGateway, when key words are entered in the
anesthesia system and eGateway recognizes the patient information related to the key words, it will
update the patient information to the anesthesia system synchronously. If the patient information in
the eGateway is updated, eGateway will also update the information to the anesthesia system
synchronously. See 4.2.1.3 (Pages 4-5) "Synchronize Patient Information".
