10 - 8 Operator’s Manual of Anesthesia System
10.5.3 Auxiliary Electrical Outlets
10.5.4 Communication Ports
10.6 Pneumatic Specifications
10.6.1 Pipeline Supply
Number of Outlets: 4
Output Voltage: Corresponds to power supply input voltage
Output Current of Each Auxiliary Outlet: 3 A max.
Output Current for Total Auxiliary
Outlet:
5 A max.
Breaker Rating Current of Each Auxiliary
Outlet:
3 A
Breaker Rating Current for Total
Auxiliary Outlet:
5 A
TABLE 10-7 Auxiliary Electrical Outlets
RS-232 Communication Port: One DB9 male connector. Provides a non-isolated output
serial RS232C interface. It is used for connection of
calibration equipment by a Mindray-authorized service
representative.
NOTE: Do not connect any non-isolated
devices to the DB9/RS232C interface
of the Anesthesia System.
Network Port: Two separate RJ-45 network ports
SB Ports: Four SB ports
CAUTION: Do not connect any devices to the SB
ports other than Mindray approved
USB storage devices and a supported
USB mouse.
Video Signal Port: One DB15 female port for outputting the video signal of the
main display to external display.
TABLE 10-8
Communication Ports
Pipeline Input Pressure Range: O
2
: 280 to 600 kPa (40 to 87 psi)
N
2
O: 280 to 600 kPa (40 to 87 psi)
Air: 280 to 600 kPa (40 to 87 psi)
Pipeline Input Flow Rate Range: O
2
: V'max. 190 L/min
Air: V'max. 70 L/min
N
2
O: V'max. 20 L/min
Pipeline Connections: DISS body complying with CGA V-5
Gas Configuration: N2O, Air, O2
TABLE 10-9
Pipeline Supply
