Constr
aints Among V
entilation Par
ameters
Par
ameters and F
actory Defaults
B - 14
Operator’
s Manual of Anesthesia
System
B.12
Constraints
Among V
entil
atio
n Parameters
V
ENTILATION
MODES
P
ARAMETERS
PARAMETER RELATION FORMULA
VCV
RR
4 ≤ RR ≤ 100
Vt
10 ≤ Vt ≤
2000
Plimit
Plimit ≥ PEEP+5
SIMV-
VC
RR
4 ≤ RR≤ 100
Vt
10 ≤ Vt ≤
2000
ΔPsupp (fr
om
VCV
, PC
V-VG)
ΔPsupp ≤ Plimit-PEEP
3 ≤ ΔPsupp ≤ 60
Plimit
Plimit ≥ PEEP+5
Plimit ≥ ΔPsupp+PEEP
PCV
RR
4 ≤ RR ≤ 100
Pinsp
If Pinsp is configur
ed:
Pins
p≥
PEE
P+
5
5≤Pinsp≤
90
If ΔPinsp is configured:
ΔPinsp≤90 - PEE
P
5≤ΔPin
sp≤70
259
261
