11.1.3 High-Flow O2 Therapy Flowmeter Assembly, and System Switch

Assembly

No. Name P/N Test Item After

Replacement

Remarks

High-flow O2 therapy

flowmeter assembly

115-065008-00

5.9.1 High-flow O2

supply test

2 System switch assembly 115-064077-00

5.2 System check;

5.7.1 Vaporizer

Monitoring Function Test
