Display & Cine Review 6-3
 Press [Dual] / [Quad] to switch between dual-splitting and quad-splitting mode.
 Press <Single> on the control panel to enter the single display format, which displays the
currently activated window. In single display format, press <Dual>/<Quad> to return to
splitting display mode.
 Unfrozen: in splitting display status, when you unfreeze the image you can only unfreeze
the image in the activated window, other images still keep frozen. In single-window display
status, the system displays single image after being unfrozen.
6.4 Cine Review
After you press the <Freeze> key, the system allows you to review and edit the images prior to the
image frozen. This function is called as cine review. The magnified images can also be reviewed
after the <Freeze> key is pressed, and the operating method is the same. You can perform zoom,
measurements, add comments and body marks on the images being reviewed.
The system supports manual review as well as automatic review. The default setup is Manual Cine,
but you can switch between Auto Cine and Manual Cine.
In addition, the system supports the images reviewed along with physiological waveforms, if the
detection of physiological waveforms is performed.
CAUTION:
1.
Cine Review images can be inadvertently combined in-between separate
patient scans. The Cine Review memory must be cleared at the end of the
current patient and the onset of the next new patient by pressing the
<End Exam> key on the control panel.
2.
Cine files stored in the system’s hard drive shall contain patient
information, to avoid the selection of an incorrect image file and potential
misdiagnosis.
6.4.1 Entering/ Exiting Cine Review
 To enter Cine Review:
 The system enters the manual cine review status once press <Freeze> to freeze the
image.
 Open cine files in thumbnail, iStation or Review, the system enters automatic cine review
status.
 swipe the touch screen left or right to review the cine.
 To exit Cine Review:
Press <Freeze> or <B>, the system will return to image scanning and exit cine review.
6.4.2 Cine Review in 2D Mode
(B/B+Color/B+Power/B+TVI/B+TEI)
 Manual Cine Review:
After entering the cine review of 2D mode, roll the trackball or slide the screen to review the
cine images on the screen one by one.
If you roll the trackball left or slide the screen left, the review sequence is reversed to the
image-storing sequence, thus the images are displayed in descending order. Whereas, if you
roll the trackball right or slide the screen left, the review sequence is the same as the image-
storing sequence, thus the images are displayed in ascending order. When you review images
until the first or the last frame, further rolling the trackball will display the last or first frame.
The cine progress bar at the bottom of the screen (as shown in the figure below):
