System Preparation 3-1
3 System Preparation
Do not connect the three-wire cable of the system with a two-
wire plug without protective grounding; otherwise, electric
shock may result.
Do connect the power plug of this system to wall receptacles
that meet the ratings indicated on the rating nameplate. If
adapters or multifunctional receptacles are used, it may cause
the leakage current to exceed the safety requirement.
In the environment that patient is 1.5 meters around, connect
peripherals to the auxiliary power outlet which is capable of
isolation protection, or power the peripherals by auxiliary
output cable or isolation transformer complied with IEC 60601-
1-2:2014 or the power input of the same safety level.
DO NOT use power supply of different phases to power
peripherals.
When using peripherals not powered by the auxiliary output of
the ultrasound system, or using peripherals other than
permitted by Mindray, make sure the overall leakage current of
peripherals and the ultrasound system meets the requirement
of the local medical device electrical regulation (like enclosure
leakage current should be no more than 500uA of IEC 60601-1-
2:2014), and the responsibility is held by the user.
3.1 Move / Position the System
Please read and understand the safety precautions before placing the system to ensure safety for
both operator and devices.
1. Switch off the power, and pull out the plug.
2. Disconnect all cables from the off-board peripheral devices (printer, recorder, etc.).
3. Release the four casters, and hold the handle to move the system.
4. When you move the system to a desired location, lock the four casters.
Maintain a generous – free air flowing space around the back and
both sides of the system; failure may result due to increased rise
in system operating temperature.
Pay extra attention when moving the system on a sloping ground,
do not move it on a more than 10°-sloped plane to avoid system
toppling.
