8 SYSTEM APPLICATION EXAMPLES
Application Example 2 8-133
8.2.12 Transmission delay time
Calculate the delay time [ms] in transmission from the safety CPU module to the robot controller. The following
shows calculation examples.
Table 8-16 Parameters
Item
Description
Value
Remarks
SCcpu
Safety cycle time of the safety CPU module
3.00[ms]
Setting value
SCrc
Safety cycle time of the robot controller
7.11[ms]
-
LS
Communication cycle intervals
1.00[ms]
Setting value
TMact
Transmission interval monitoring time on the active
side
(Transmission interval monitoring time to be set on
the safety programmable controller)
16.30[ms]
Setting value
TMpas
Transmission interval monitoring time on the
passive side
(Transmission interval monitoring time to be set on
the robot controller)
21.40[ms]
Setting value
・ Safety CPU module → Robot controller (normal value)
SCsnd + LS + SCrcv + TMsnd + (SCrc × 1.5)
= SCcpu + LS + SCrc + TMact + (SCrc × 1.5)
= 3.00 + 1.00 + 7.11 + 16.30 + (7.11 × 1.5)
= 38.08
・ Safety CPU module → Robot controller (maximum value)
SCsnd + (LS × 2) + (SCrcv × 2) + TMsnd + (SCrc × 1.5)
= SCcpu + (LS × 2) + (SCrc × 2) + TMact + (SCrc × 1.5)
= 3.00 + (1.00 × 2) + (7.11 × 2) + 16.30 + (7.11 × 1.5)
= 46.19
