Monitor display and monitor output signal
4.11.2 DU/PU monitor display selection
(Pr. 52, Pr. 54, Pr. 158, Pr. 170, Pr. 171, Pr. 268, Pr. 563, Pr. 564, Pr. 891)
(1) Monitor description list (Pr. 52)
⋅ Set the monitor to be displayed on the operation panel (FR-DU07) and parameter unit (FR-PU04/FR-PU07) in Pr.
52 DU/PU main display data selection.
⋅ Set the monitor to be output to the terminal FM(pulse train output) in Pr. 54 FM terminal function selection.
⋅ Set the monitor to be output to the terminal AM (analog output (0 to 10VDC voltage output)) in Pr. 158 AM terminal
function selection.
⋅ Refer to the following table and set the monitor to be displayed. (The signals marked × cannot be selected for
monitoring)
The monitor to be displayed on the main screen of the operation panel (FR-DU07)/parameter unit (FR-PU04/FR-
PU07) can be selected.
Parameter
Number
Name Initial Value Setting Range Description
52
DU/PU main display data
selection
0
(output
frequency)
0, 5, 6, 8 to 14,
17, 20, 23 to 25,
50 to 57, 100
Select the monitor to be displayed on the
operation panel and parameter unit.
Refer to the following table for monitor description.
54
FM terminal function
selection
1
(output
frequency)
1 to 3, 5, 6, 8 to
14, 17, 21, 24,
50, 52, 53
Select the monitor output to terminal FM.
158
AM terminal function
selection
Select the monitor output to terminal AM.
170 Watt-hour meter clear 9999
0 Set “0” to clear the watt-hour meter monitor.
10
Set the maximum value when monitoring from
communication to 0 to 9999kWh.
9999
Set the maximum value when monitoring from
communication to 0 to 65535kWh.
171 Operation hour meter clear 9999 0, 9999
Set “0” in the parameter to clear the watt-hour
monitor.
Setting “9999” has no effect.
268 *
Monitor decimal digits
selection
9999
0 Displayed as integral value.
1 Displayed in 0.1 increments.
9999 No function
563
Energization time
carrying-over times
0
0 to 65535
(reading only)
The numbers of cumulative energization time
monitor exceeded 65535h is displayed. Reading
only
564
Operating time carrying-
over times
0
0 to 65535
(reading only)
The numbers of operation time monitor
exceeded 65535h is displayed. Reading only
891
Cumulative power monitor
digit shifted times
9999
0 to 4
Set the number of times to shift the cumulative
power monitor digit.
Clamp the monitoring value at maximum.
9999
No shift
Clear the monitor value when it exceeds the
maximum value.
The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 156)
* The above parameters allow its setting to be changed during operation in any operation mode even if "0" (initial value) is set in
Pr. 77 Parameter write selection.
Types of Monitor Increments
Pr. 52 Parameter
Setting Value
Pr. 54 (FM)
Pr. 158 (AM)
Parameter
Setting
Value
Full-scale
value of the
terminal FM
and AM
Description
DU LED
PU main
monitor
Output frequency 0.01Hz 0/100 1 Pr. 55 Displays the inverter output frequency.
Output current
0.01A/0.1A
*5
0/100 2 Pr. 56
Displays the inverter output current effective
value.
Output voltage 0.1V 0/100 3 400V Displays the inverter output voltage.
Alarm display

0/100
×

Displays 8 past alarms individually.
Frequency setting 0.01Hz 5
*1
5 Pr. 55 Displays the set frequency.
Running speed 1(r/min) 6
*1
6
The value
converted
with the Pr.
37 value
from Pr. 55
Displays the motor speed.
(depending on Pr.
37
and Pr. 144 settings. (For details, refer to page
115 .)
