*1 These instruction codes are used for parameter read and write by using Mitsubishi inverter protocol with the RS-485 communication.
(Refer to page 177 for RS-485 communication)
*2 "{" indicates valid and "×" indicates invalid of "parameter copy", "parameter clear", and "all parameter clear".
Symbols in the table indicate parameters which function when an option is mounted.
........ FR-A7AX, ......... FR-A7AY, ......... FR-A7AR, ......... FR-A7AP, ......... FR-A7NC, ........ FR-A7ND,
........ FR-A7NL, ......... FR-A7NP
Appendix 2 Control mode-based parameter (function) correspondence
table and instruction code list
Parameter Name
Instruction Code * 1
Parameter
Copy
*3
Parameter
Clear
*3
All Parameter
Clear
*3
Read Write Extended
0
Torque boost
00 80 0
{{{
1
Maximum frequency
01 81 0
{ { {
2
Minimum frequency
02 82 0
{{{
3
Base frequency
03 83 0
{ { {
4
Multi-speed setting (high speed)
04 84 0
{{{
5
Multi-speed setting (middle speed)
05 85 0
{ { {
6
Multi-speed setting (low speed)
06 86 0
{{{
7
Acceleration time
07 87 0
{ { {
8
Deceleration time
08 88 0
{{{
9
Electronic thermal O/L relay
09 89 0
{ { {
10
DC injection brake operation frequency
0A 8A 0
{{{
11
DC injection brake operation time
0B 8B 0
{ { {
12
DC injection brake operation voltage
0C 8C 0
{{{
13
Starting frequency
0D 8D 0
{ { {
14
Load pattern selection
0E 8E 0
{{{
15
Jog frequency
0F 8F 0
{ { {
16
Jog acceleration/deceleration time
10 90 0
{{{
17
MRS input selection
11 91 0
{ { {
18
High speed maximum frequency
12 92 0
{{{
19
Base frequency voltage
13 93 0
{ { {
20
Acceleration/deceleration reference
frequency
14 94 0
{{{
21
Acceleration/deceleration time
increments
15 95 0
{ { {
22
Stall prevention operation level
(Torque limit level )
16 96 0
{{{
23
Stall prevention operation level
compensation factor at double speed
17 97 0
{ { {
24
Multi-speed setting (speed 4)
18 98 0
{{{
25
Multi-speed setting (speed 5)
19 99 0
{ { {
26
Multi-speed setting (speed 6)
1A 9A 0
{{{
27
Multi-speed setting (speed 7)
1B 9B 0
{ { {
28
Multi-speed input compensation
selection
1C 9C 0
{{{
29
Acceleration/deceleration pattern
selection
1D 9D 0
{ { {
30
Regenerative function selection
1E 9E 0
{{{
31
Frequency jump 1A
1F 9F 0
{ { {
32
Frequency jump 1B
20 A0 0
{{{
33
Frequency jump 2A
21 A1 0
{ { {
34
Frequency jump 2B
22 A2 0
{{{
35
Frequency jump 3A
23 A3 0
{ { {
36
Frequency jump 3B
24 A4 0
{{{
37
Speed display
25 A5 0
{ { {
41
Up-to-frequency sensitivity
29 A9 0
{{{
42
Output frequency detection
2A AA 0
{ { {
43
Output frequency detection for reverse
rotation
2B AB 0
{{{
