Outline dimension drawings
7.3 Outline dimension drawings
7.3.1 Inverter outline dimension drawings
• FR-F720-0.75K, 1.5K
• FR-F720-2.2K, 3.7K, 5.5K
• FR-F740-0.75K, 1.5K, 2.2K, 3.7K, 5.5K
(Unit: mm)
2-φ6 hole
D
260 245
7.5
6
110
95
5
7.5
D1
Inverter Type D D1
FR-F720-0.75K 110 21
FR-F720-1.5K 125 36
260
150
125
6
140
5
7.5 7.5245
2-φ6 hole
144
45.5
* The FR-F740-0.75K to
2.2K are not provided
with a cooling fan.
