4.21.2 Display of the life of the inverter parts (Pr. 255 to Pr .259)
(1) Life alarm display and signal outuput (Y90 signal, Pr. 255)
⋅ Whether any of the control circuit capacitor, main circuit capacitor, cooling fan and inrush current limit circuit has reached
the life alarm output level or not can be checked by Pr. 255 Life alarm status display and life alarm signal (Y90).
Degrees of deterioration of main circuit capacitor, control circuit capacitor, cooling fan and inrush current limit
circuit can be diagnosed by monitor.
When any part has approached the end of its life, an alarm can be output by self diagnosis to prevent a fault.
(Use the life check of this function as a guideline since the life except the main circuit capacitor is calculated
theoretically.)
For the life check of the main circuit capacitor, the alarm signal (Y90) will not be output if a measuring method of
(4) is not performed.
Parameter
Number
Name Initial Value Setting Range Description
255 Life alarm status display 0 (0 to 15)
Display whether the control circuit capacitor,
main circuit capacitor, cooling fan, and each
parts of the inrush current limit circuit has
reached the life alarm output level or not.
Reading only
256
Inrush current limit circuit
life display
100% (0 to 100%)
Display the deterioration degree of the inrush
current limit circuit. Reading only
257
Control circuit capacitor life
display
100% (0 to 100%)
Display the deterioration degree of the control
circuit capacitor. Reading only
258
Main circuit capacitor life
display
100% (0 to 100%)
Display the deterioration degree of the main
circuit capacitor. Reading only
The value measured by Pr. 259 is displayed.
259
Main circuit capacitor life
measuring
0
0, 1
(2, 3, 8, 9)
Setting "1" and switching the power supply off
starts the measurement of the main circuit
capacitor life.
When the Pr. 259 value is "3" after powering on
again, the measuring is completed. Read the
deterioration degree in Pr. 258.
The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 156.)
Pr. 255
(decimal)
Bit
(binary)
Inrush
Current Limit
Circuit Life
Cooling
Fan Life
Main Circuit
Capacitor Life
Control Circuit
Capacitor Life
15 1111 {{ { {
14 1110 {{ { ×
13 1101 {{ × {
12 1100 {{ ××
11 1011 { × {{
10 1010 { × { ×
9 1001 { ×× {
8 1000 { ×× ×
7 0111 × {{ {
60110 × {{ ×
5 0101 × { × {
4 0100 × { ××
30011 ×× {{
2 0010 ×× { ×
1 0001 ×× × {
0 0000 ×× × ×
{: With warnings, ×: Without warnings
0 0 0 0 0 0 0 0 0 0 0 0 1 0 0
bit0 Control circuit capacitor life
1
15bit 7 0
bit1 Main circuit capacitor life
bit2 Cooling fan life
bit3 Inrush current limit circuit life
• Pr.255 read
Bit image is displayed
in decimal
• Pr.255 setting read
