Frequency setting by external terminals
4.6 Frequency setting by external terminals
4.6.1 Multi-speed setting operation (Pr. 4 to Pr. 6, Pr. 24 to Pr. 27, Pr. 232 to Pr. 239)
The above parameters allow its setting to be changed during operation in any operation mode even if "0" (initial value) is set in Pr. 77 Parameter write selection.
* The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 156)
Purpose Parameter that must be Set Refer to Page
Make frequency setting by
combination of terminals
Multi-speed operation
Pr. 4 to Pr. 6, Pr. 24 to Pr. 27,
Pr. 232 to Pr. 239
84
Perform jog operation Jog operation Pr. 15, Pr. 16 86
Added compensation for multi-speed
setting and remote setting
Multi-speed input
compensation selection
Pr. 28 88
Infinitely variable speed setting by
terminals
Remote setting function Pr. 59 89
Can be used to change the preset speed in the parameter with the contact terminals.
Any speed can be selected by merely turning on-off the contact signals (RH, RM, RL, REX signals).
Parameter
Number
Name
Initial
Value
Setting Range Description
4 Multi-speed setting (high speed) 60Hz 0 to 400Hz Set the ferquency when RH turns on.
5 Multi-speed setting (middle speed) 30Hz 0 to 400Hz Set the ferquency when RM turns on.
6 Multi-speed setting (low speed) 10Hz 0 to 400Hz Set the ferquency when RL turns on.
24
*
Multi-speed setting (speed 4) 9999 0 to 400Hz, 9999
Frequency from speed 4 to speed 15 can
be set according to the combination of
the RH, RM, RL and REX signals.
9999: not selected
25
*
Multi-speed setting (speed 5) 9999 0 to 400Hz, 9999
26
*
Multi-speed setting (speed 6) 9999 0 to 400Hz, 9999
27
*
Multi-speed setting (speed 7) 9999 0 to 400Hz, 9999
232
* Multi-speed setting (speed 8) 9999 0 to 400Hz, 9999
233
* Multi-speed setting (speed 9) 9999 0 to 400Hz, 9999
234
* Multi-speed setting (speed 10) 9999 0 to 400Hz, 9999
235
* Multi-speed setting (speed 11) 9999 0 to 400Hz, 9999
236
* Multi-speed setting (speed 12) 9999 0 to 400Hz, 9999
237
* Multi-speed setting (speed 13) 9999 0 to 400Hz, 9999
238
* Multi-speed setting (speed 14) 9999 0 to 400Hz, 9999
239
* Multi-speed setting (speed 15) 9999 0 to 400Hz, 9999
(1) Multi-speed setting (Pr. 4 to Pr. 6)
â‹… Operation is performed at the frequency set in Pr. 4 when the RH
signal turns on, Pr. 5 when the RM signal turns on, and Pr. 6 when the
RL signal turns on.
(2) Multi-speed setting higher than speed 4 (Pr. 24 to Pr. 27,
Pr. 232 to Pr. 239)
â‹… Frequency from speed 4 to speed 15 can be set according to the
combination of the RH, RM, RL and REX signals. Set the running
frequencies in Pr. 24 to Pr. 27, Pr. 232 to Pr. 239. (In the initial value
setting, speed 4 to speed 15 are unavailable.).
â‹… For the terminal used for REX signal input, set "8" in any of Pr. 178 to
Pr. 186 to assign the function.
*1 When "9999" is set in Pr.232 Multi-speed setting (speed 8), operation is performed at
frequency set in Pr.6 when RH, RM and RL are turned off and REX is turned on.
ON
ON ON ON ON
ON ON
ONONON
ON
Output frequency (Hz)
Speed 1
(High speed)
Speed 2
(Middle speed)
Speed 3
(Low speed)
Speed 4
Speed 5
Speed 6
Speed 7
Time
RH
RM
RL
REMARKS
â‹… In the initial setting, if two or three speeds are simultaneously
selected, priority is given to the set frequency of the lower signal. For
example, when the RH and RM signals turn on, the RM signal (Pr. 5)
has a higher priority.
â‹… The RH, RM, RL signals are assigned to the terminal RH, RM, RL in
the initial setting.
By setting "0 (RL)", "1 (RM)", "2 (RH)" in any of Pr.178 to Pr.189 (input
terminal function assignment), you can assign the signals to other
terminals.
Time
Speed 8
ONON ON ON ON ON ON ON
ON ON ON ON
ON ON ON ON
ON ON ON ON
RH
RM
RL
REX
Output frequency
(Hz)
*
Speed 9
Speed 10
Speed 11
Speed 12
Speed 13
Speed 14
Speed 15
Multi-Speed Operation
Connection Example
10
2
5
Inverter
STF
REX
RH
RM
RL
Multi-speed selection
Frequency setting
potentiometer
Forward
rotation
SD
