Mitsubishi Electric MELFA RV-2SDB Series User Manual

Operation of Teaching Box R32TB Enter a character
SD-/SQ series 6 - 5
6.2 Enter a character
Every time you press the [CHARACTER] key, the write mode switches between entry of numbers and
letters. The current mode is displayed at the bottom in the middle of the display.
Enter numbers
Numbers are entered in number mode using the keys on which the appropriate number as well as the
minus sign and the full stop are shown at the bottom left.
쑶
Enter letters
Letters are entered in letter mode using the keys on which the appropriate number indicated on the
bottom right. Change the character by pressing the key repeatedly. For instance, pressing the [ABC]
key repeatedly allows you to select from the following characters: "A"
... "B" ... "C" ... "a" ... "b" ... "c".
When selecting letters assigned to the same key, you can move the cursor along a position by using
the arrow key [].
쑶
The following characters are assigned to the keys:
● [ ’ ( ) ] key: ’  (  )  “  ^  :    ¥  ?
● [ @ = ] key: @  =  +  –  얖  /  <  >
● [ , % ] key: ,  %  #  $  !  &  _  .
Example쑴
"51" is entered as the program name.
To do this, press the [CHARACTER] key and keys [5] and [1].
R001489E
Fig. 6-2: Enter numbers
Example쑴
How to enter letters "ABY".
Press the following keys: 1 x [ABC], [], 2 x [ABC], 3 x [WXYZ].
R001489E
Fig. 6-3: Enter letters
<NEW PROGRAM>
PROGRAM NAME
(
)
CLOSE
123
<NEW PROGRAM>
PROGRAM NAME
(
51 )
CLOSE
123
<NEW PROGRAM>
PROGRAM NAME
(
ABY )
CLOSE
ABC
<NEW PROGRAM>
PROGRAM NAME
(
)
CLOSE
ABC
