Connection EMERGENCY-STOP connection
SD-/SQ series 4 - 7
4.3 EMERGENCY-STOP connection
Connection for EMERGENCY-STOP pushbutton is using the plug on the rear of the unit.
The EMERGENCY-STOP inputs are normally blank (see Fig. 4-8). The EMERGENCY-STOP pushbutton,
the door closing contact and the enable switch (enabling) unit must be connected by the user.
R001771E
Fig. 4-7: Connection for EMERGENCY-STOP circuit
Control unit CR2DA or drive unit DU2A
EMGIN
Ferrite core
 30 cm
EMGOUT
Control unit CR1DA or drive unit DU1A
 30 cm
Ferrite core
EMGIN
