4G9 ENGINE (E–W) – Front Case and Oil pump
11A-10-1a
PWEE9502
E
May 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC (4G94 Except for PAJERO io)>
10 Nm
19 Nm
14 Nm
44 Nm
39 Nm
11 Nm
13
1
10
11
12
2
3
7
6
4
8
9
16
17
18
15
14
19
9 Nm
24 Nm
11 Nm
10 Nm
5
7 Nm
Apply engine oil to all
moving parts before
installation.
Removal steps
"FA 1. Oil pressure switch
"EA 2. Oil filter
3. Drain plug
4. Drain plug gasket
5. Cover
6. Baffle plate
AB""DA 7. Upper oil pan
"DA 8. Lower oil pan
9. Oil screen
10. Oil screen gasket
11. Relief plug
12. Relief spring
13. Relief plunger
"CA 14. Oil seal
"BA 15. Oil pump case
16. O-ring
17. Oil pump case cover
AC""AA 18. Outer rotor
AC""AA 19. Inner rotor
PWEE9502-K
E
Jun. 2002Mitsubishi Motors Corporation Revised
