Mitsubishi 4G9 User Manual

4G9 ENGINE (E-W) -
Rocker Arms and Camshafts
11A-8-2
PWEE9502
E
May 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <DOHC>
3
7
2
3.5 Nm
4
1
5
6
11 Nm
24 Nm
9
10
11
8
12
13
Apply engine oil to
all moving parts
before installation.
14
15
Removal steps
1. Breather hose
2. P.C.V. hose
3. P.C.V. valve
4. P.C.V. valve gasket
5. Oil filler cap
"
K
A
6. Rocker cover
7. Rocker cover gasket A
8. Rocker cover gasket B
"
J
A
9. Semi-circular packing
10. Oil seal
"
H
A
11. Bearing cap
"
G
A
12. Intake camshaft
"
G
A
13. Exhaust camshaft
14. Rocker arm
A
A
""
F
A
15. Lash adjuster
PWEE9502-G
E
May 2000Mitsubishi Motors Corporation Revised
