4G9 ENGINE (E-W) -
Piston and Connecting Rod
11A-11-1
PWEE9502
E
May 1995Mitsubishi Motors Corporation
11. PISTON AND CONNECTING ROD
REMOVAL AND INSTALLATION
Lubricate all inter-
nal parts with en-
gine oil during re-
assembly.
6
7
8
10
12
9
11
4
5
3
2
1
Removal steps
"
G
A
1. Nut
A
A
""
F
A
2. Connecting rod cap
"
E
A
3. Connecting rod bearing
"
D
A
4. Piston and connecting rod
"
E
A
5. Connecting rod bearing
"
C
A
6. Piston ring No. 1
"
C
A
7. Piston ring No. 2
"
B
A
8. Oil ring
A
B
""
A
A
9. Piston pin
10. Piston
11. Connecting rod
12. Bolt
