BODY REPAIR
BASE OF BODY REPAIR
9-25
POSITIONING DIMENSIONS FOR OPENINGS
M4090010000012
When replacing the panel of the opening of the front
pillar, center pillar and other openings, make a point
to securely bite the poltapower, etc. so the position of
the opening is not off-center. Upon assembling,
adjust the opening dimensions to the standard speci-
fications and then weld.
STANDARD PROCEDURES FOR SHEET METAL WORK
M4090012000018
REPAIRS USING A HAMMER AND DOLLY
It a damaged external panel, etc., can be reused, the
usual way to repair it is by using a hammer and dolly
to hammer out the damaged area. The following
describes these repair procedures.
.
1. Check whether or not there is foreign material (mud, etc.) on
the panel surface. If so, clean it away.
CAUTION
The surface of the hammer and dolly must be free of scars,
etc.
2. Select the appropriate hammer and dolly to be used
according to the panel shape.
AB200100
PORTA POWER
AB
