STIFFENER AND DAMP SHEET APPLICATION LOCATIONS
BODY CONSTRUCTION
1-24
STIFFENER AND DAMP SHEET APPLICATION LOCATIONS
M4010008000103
Sound insulation was improved with anti-vibration
effects and heightening surface rigidity with a stiff-
ener on the inner side of the side outer panel, and
roof panel, as well as a damping sheet adhered to
the inner side of the front door.
NOTE: The main contents of a stiffener are epoxy
resin. It comes in a sheet form and contains a mix-
ture of glass fiber and filler, and cures (stiffens) when
heated. It is used to improve the rigidity of the outer
plate.
AB201919
AB
STIFFENER
STIFFENER
(VHIECLES WITH SUNROOF)
DAMP SHEET
STIFFENER
AB201920
AB
DAMP SHEET
