Mitsubishi LANCER EVOLUTION 2003 Body Repair Manual

BODY CONSTRUCTION CHARACTERISTICS
BODY CONSTRUCTION
1-8
BODY CONSTRUCTION CHARACTERISTICS
FRONT BODY
M4010010000092
HEADLAMP SUPPORT
By adopting a steel sheet with variable thickness* for
the front end crossmember outer, the steel sheet
thickness on the right side of the vehicle has been
increased to improve safety in collision and body
rigidity.
NOTE: *: Steel sheets with different thickness
welded to form one steel sheet.
AB201017
AB
10
1
4
2
5 3
6
7
8
9
11
1. FRONT END UPPER BAR
2. SENSOR BRACKET
3. HEADLAMP SUPPORT PANEL
4. HOOD LOCK STAY
5. FRONT END CROSSMEMBER INNER
REINFORCEMENT
6. A/C CONDENSER BRACKET
7. RADIATOR BRACKET
8. FRONT END CROSSMEMBER INNER
9. FRONT END CROSSMEMBER OUTER
10. SHIPPING HOOK
10. FRONT END CROSSMEMBER REINFORCEMENT
