Mitsubishi LANCER EVOLUTION 2003 Body Repair Manual

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
BODY DIMENSIONS
2-12
FRONT BODY
M4020006000078
AB201758
AB
mm (in)
24
25
26
27
28
29
30
31
BODY CENTER POINT
1,437
(56.6)
885
(34.8)
691
(27.2)
1,390
(54.7)
543
(21.4)
894
(35.2)
1,040
(40.9)
1,558
(61.3)
1,382
(54.4)
730
(28.7)
1,508
(59.4)
749
(29.5)
1,091
(43.0)
870
(34.3)
665
(26.2)
328
(12.9)
32
753
(29.6)
873
(34.4)
872
(34.3)
AB201759
AB
33
34
1,050
(41.3)
590
(23.2)
700
(27.6)
894
(35.2)
782
(30.8)
35
36
314
(12.4)
901
(35.5)
547
(21.5)
732
(28.8)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
24 Center of front end
crossmember upper water
draining hole
Round−8 (0.3)
25 Center of harness clip
mounting hole
Oblong−7×12
(0.3×0.5)
26 Center of intercooler pipe
mounting hole
Round−9 (0.4)
27 Center of front fender
mounting hole
Round−6.6 (0.3)
28 Center of front strut
mounting hole
Round−11.5
(0.5)
29 Notch of front deck (Body
center point)
−
30 Center of front fender
mounting hole
Round−6.6 (0.3)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
