TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
BODY DIMENSIONS
2-14
SIDE BODY
M4020007000071
AB201760
AB
37
38
39
40
41
42
43
44
45
mm (in)
716
(28.2)
863
(34.0)
808
(31.8)
688
(27.1)
581
(22.9)
902
(35.5)
875
(34.4)
463
(18.2)
1,084
(42.7)
1,127
(44.4)
1,174
(46.2)
46
828
(32.6)
960
(37.8)
AB201761
AB
47
39
43
50
48
49
1,124
(44.3)
1,094
(43.1)
1,100
(43.3)
1,041
(41.0)
1,067
(42.0)
731
(28.8)
901
(35.5)
837
(33.0)
355
(14.0)
338
(13.3)
51
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
37 Front pillar positioning
notch (upper)
−
38 Front pillar positioning
notch (lower)
−
39 Side roof rail positioning
notch (front)
−
40 Side sill positioning notch
(front)
−
41 center pillar positioning
notch (upper)
−
42 center pillar positioning
notch (lower)
−
43 Side roof rail positioning
notch (rear)
−
44 Side sill positioning notch
(rear)
−
45 Quarter panel positioning
notch (upper)
−
46 Quarter panel positioning
notch (lower)
−
47 Center of front door hinge
mounting hole (upper)
Round−11 (0.4)
48 Center of front door hinge
mounting hole (lower)
Round−11 (0.4)
49 Center of rear door hinge
mounting hole (upper)
Round−11 (0.4)
50 Center of rear door hinge
mounting hole (lower)
Round−11 (0.4)
51 Center of rear door switch
mounting hole
Round−5 (0.2)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
