Mitsubishi LANCER EVOLUTION 2003 Body Repair Manual

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
BODY DIMENSIONS
2-10
SUSPENSION INSTALLATION DIMENSIONS
M4020013000144
AB201756
AB
mm (in)
3
14
15
16
17
18
10
20
23
22
389
(15.3)
295
(11.6)
906
(35.7)
713
(28.1)
437
(17.2)
293
(11.5)
741
(29.2)
387
(15.2)
1,186
(46.7)
713
(28.1)
700
(27.6)
852
(33.5)
902
(35.5)
810
(31.9)
498
(19.6)
469
(18.5)
111
(4.4)
381
(15.0)
357
(14.1)
190
(7.5)
104
(4.1)
AB201757
AB
3 16
17
20
22
10
14
15
876
(34.5)
857
(33.7)
780
(30.7)
1,075
(42.3)
1,137
(44.8)
18
1,025
(40.4)
777
(30.6)
871
(34.3)
853
(33.6)
859
(33.8)
890
(35.0)
895
(35.2)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
3 Center of crossmember
mounting hole
Round−18 (0.7)
10 Center of crossmember
mounting hole
Round−14 (0.6)
14 Tip of crossmember
mounting bolt (left)
−
15 Tip of crossmember
mounting bolt (right)
−
16 Center of crossmember
mounting hole
Round−11 (0.4)
17 Trailing arm mounting
position
−
18 Control link mounting
position
−
20 Tip of differential support
mounting bolt
−
22 Center of upper arm
mounting hole
Round−13 (0.5)
23 Center of crossmember
mounting hole
Round−15 (0.6)
No. STANDARD
MEASUREMENT POINT
HOLE SHAPE−
SIZE mm (in)
